Product Description:
In the movies, when the building's power fails there seems to be an elongated time period where the cast seemingly fights for survival. In reality, you can avoid this antagonistic element by purchasing our Bodine brand emergency ballast.
The GEN1 model works with your building's generator (or other power source) to provide emergency power for up to five (5) minutes. If the generator fails, the ballast will provide additional electricity to avoid lighting shutdown.
Features:
Ballast Type: Emergency
Lamp Wattage: 17-55W
Input Wattage: 1.5W
Universal 120-277vAC, 60Hz cycles
Operates: One linear T5, T12 or long compact fluorescent lamp
Lumens (at 10-feet): 1050 - 3200 lm
Min/Max Temp: 32° to 131°F
Includes LED charging indicator
5-year full warranty
Application:
This emergency ballast works to provide emergency power to generators for up to five (5) minutes. It's ideal for lighting units that will not accept standard battery pack sizes including cove, architectural, surface-mount and NSF vapor proof fixtures.
External Specifications:
The GEN1 has a long, skinny profile and has an unfinished metal case that keeps moisture away from the circuitry. Mounting feet on both ends allow for installation in tight spaces or ballast channels. Input and output lead wires protrude from a single end of the ballast.
Electrical Specifications:
Lamp wattage: 17-55W
Input wattage: 1.5W
Input current: 90mA
Universal 120-277vAC, 60 Hz
Initial illumination: 1050 - 3200 (depending on lamp)
Battery: Maintenance-free nickel cadmium. 7-10 year lifespan
Emergency runtime: +90 minutes
Recharge time: 24 hours or less
Charging current: 90mA
LED diagnostic switch for redundant manual testing
Dimensions:
Width: 9.40"
Depth: 2.40"
Height: 1.50"
Mounting center: 8.9"
Weight: 2.2 lbs
Compliance:
Tested to UL924 standards for Emergency Lighting & Power Equipment
CSA C22.2 No. 141 certified
NEC Installation standards
Meets NFPA: 101 Life Safety Code, excerpt 5-9.3 periodic testing standards
National Fire Code
National Building Code
This emergency device is warranted for five (5) full years from the date of purchase. This warranty will only cover properly-installed transformers used under NEC guidelines. During the warranty period, the manufacturer will repair or replace without charge to the user.
